Açıklama
Çok amaçlı bağlantı panelleri, kontrol panelinden güç desteği, harici projektör ve ekran aygıtlarına ve ses sistemlerine erişim olanağı sağlar. Hoparlörler, sesleri gelişmiş mikrofon aracılığıyla daha hassas bir şekilde iletebilir. Platformdaki ekstra alanlar tablet ve aksesuar yerleştirmek için uygundur.
| MODEL NO | ML22T |
| Main Specifications | |
| Speaker Screen | 22″ Full HD Multi Touch Capacitive Touch Screen |
| Built-in PC for Speaker Screen | intel 4.10 GHz CPU, 4GB Ram, 120 GB SSD, Win 10 Pro |
| Switch | Atlona SC-500 3×1 switcher with two HDMI inputs and one VGA input |
| Scalar | HD video scaler with HDMI output and input resolution control |
| Source selection | Automatic input selection and automatic display control |
| Sliding cover | Available for top podium with lock |
| Microphone | 1 pcs 18″ Shure Gooseneck Condenser Microphone |
| Tablet controller | Optional |
| Detailed Specifications | |
| Lecturer Panel | 22″ |
| Screen Specifications | |
| Resolution | 1920×1080 FHD |
| Brightness | 250 cd/m2 |
| Panel Type | IPS |
| Aspect ratio | 16:9 |
| Touch Technology | Capacitive |
| Touch Points | 10 points |
| Lecturer Panel PC Specifications | |
| CPU | Intel 4.10 GHz |
| RAM | 4 GB DDR4 |
| HDD | 120 GB SSD |
| Operating System | Windows 10 Pro |
| Microphone | |
| Length | 18″ |
| No of microphone | 1 pcs |
| Output Connector | 3-way XLR (Male) |
| Polar Pattern | Cardioid |
| Frequency Response | 70-16000 Hz |
| Sensitivity (at 1,000Hz) | –33 dBV/Pa[1] (22 mV) |
| Impedance | 180 Ω |
| Power ON indicator | LED |
| Power requirement | Phantom Power (48V) |
| Timer & Chronometer | |
| Screen size | 3,5″ |
| Clock | Available |
| Timer | Available |
| Stopwatch | Available |
| Touch | Single touch |
| Inputs | |
| VGA | Available (On desk for Laptop) |
| Sound | 3,5mm jak (On desk for Laptop) |
| HDMI | Available (On desk for Laptop) |
| Ethernet | Available (On desk for Laptop) |
| 230V Plug (Max 5A) | Available (On desk for Laptop / mobile phone charge) |
| USB | USB 2.0 and USB 3.0 (for internal PC) |
| Outputs (Bottom of Podium) | |
| HDMI | Available |
| Ethernet | Available |
| XLR for microphone | Available |
| USB | USB 2.0 (for internal PC) |
| Power | |
| Power Input | 230V 50Hz |
| Power Consumption | 550W (max) |
| Peripherals &other features | |
| Color | Grey (RAL 7047) |
| Services door | two sided servis door |
| Drawer | Available |
| Packing | Wooden box export packing |
| Mechanical Specs | |
| Outline Dimension (mm) | Set: 754 x 810 x 1049 Package: 890 x 906 x 1255 |
| Weight (kg) | Set: 104 kg Package: 161 kg |
| Optional features | Flight case |
