Model: | LS22R |
Display Parameters: | |
Screen Size | 21,5″ |
Screen Thickness | 8mm |
Resolution | 1920*1080 |
Brightness | 300 cd/m² |
Aspect Ratio | 16:9 |
Contrast Ratio | 700:1 |
View Angle | 80/80/80/80 |
Touch | N/A |
Tilting: | |
Screen Titling / Rotation Angle | Fixed 15° |
Interface: | |
USB | 2 |
HDMI | 1 |
VGA | 1 |
RS485 in/out | 1 |
One-way Running Time | 16s |
Technique: | |
Color | Silver/Black |
Panel Material | Aluminium Alloy |
Panel Surface | Anodized sand brushed/ sandblast finishing |
Power: | |
Voltage | 110/220V |
Frequency | 50Hz |
Power Consumption | <60W |
Drive Method | Micro motor with sliding rails and belt wheel on both hand sides |
Control | Screen lift up/down, power on/off can be performed by manual control, centralized control through RS485 or the third-party controlling app by Ethernet. |
Dimension: | |
Panel Size | 738*95*4mm |
Cutting Size | 723*87mm |
Whole Frame Size | 738*95*700mm |
