| Model: | LS17R |
| Display Parameters: | |
| Screen Size | 17,3″ |
| Screen Thickness | 8mm |
| Resolution | 1920*1080 |
| Brightness | 400 cd/m² |
| Aspect Ratio | 16:9 |
| Contrast Ratio | 700:1 |
| View Angle | 80/80/80/80 |
| Touch | N/A |
| Tilting: | |
| Screen Titling / Rotation Angle | Fixed 16° |
| Interface: | |
| USB | 2 |
| HDMI | 1 |
| VGA | 1 |
| RS485 in/out | 1 |
| One-way Running Time | 10s |
| Technique: | |
| Color | Silver/Black |
| Panel Material | Aluminium Alloy |
| Panel Surface | Anodized sand brushed/ sandblast finishing |
| Power: | |
| Voltage | 110/220V |
| Frequency | 50Hz |
| Power Consumption | ＜60W |
| Drive Method | Micro motor with sliding rails and belt wheel on both hand sides |
| Control | Screen lift up/down, power on/off can be performed by manual control, centralized control through RS485 or the third-party controlling app by Ethernet. |
| Dimension: | |
| Panel Size | 435 x 75x 3 x R10 mm |
| Cutting Size | 427 x 67mm |
| Whole Frame Size | 468 x 75 x 597mm |
